KA&MELOCK KM 16

KA&MELOCK KM 16

KA&MELOCK KM 16 is an elastomer bonding agent designed for use as a topcoat.
When combined with the KA&MELOCK MP 05 primer, it is particularly suitable for applications requiring high resistance to elevated temperatures, corrosion, and dynamic loads during the vulcanization process of elastomers bonded to metal and plastic substrates.
In certain applications, KA&MELOCK KM 16 can also be used as a single-coat bonding agent.

Coating with KA&MELOCK KM 16 provides good resistance to corrosion, oils, and solvents. However, corrosion and heat resistance are significantly enhanced when the system is applied in combination with the KA&MELOCK MP 05 primer.

KA&MELOCK KM 16 enables reliable bonding of elastomer compounds based on natural rubber (NR), polyisoprene (IR), polybutadiene (BR), styrene-butadiene rubber (SBR), nitrile rubber (NBR), chloroprene rubber (CR), butyl rubber (IIR), and ethylene propylene rubber (EPDM) to a wide range of metal and plastic substrates during the vulcanization process.

The combination of KA&MELOCK MP 05 and KA&MELOCK KM 16 is particularly well suited for soft NBR and NR blends, especially in the production of transfer molding (TM) and injection molding (IM) components.

DOWNLOAD PDF

Technical Data

Colour                                                                                    Black – Green Liquid



Viscosity   4 mm DIN-Cup                                          80 – 120 s



Viscosity,cps@25°C(77°F)

                                                                                                  200 – 600 mPas

Brookfield SNB1
Spindle 2, 30 rpm



Specific Gravity                                                               0,96 – 1,04 g/cm³



Solid Content                                                                   22 – 26 % by weight



Solvents                                                                               Xylene



*Data is typical and not to be used for specification purposes.

At GOTEC Bonding Agents, precise testing and analysis are fundamental to product performance.
All KA&MELOCK bonding agents are tested, documented, and validated in our laboratories. In parallel, continuous research and development activities are carried out through ongoing product optimization in our dedicated demo and application facilities.

Our elastomer bonding solutions add reliable value to your business by enabling stable processes and trouble-free operation across a wide range of industries and applications.

KA&MELOCK bonding agents are suitable for single- or double-layer bonding systems, enabling reliable bonding of elastomer compounds to substrates such as metals, plastics, PTFE (Teflon), and textile fibers during the vulcanization process.
Please refer to the KA&MELOCK product range for detailed system recommendations.
